Rated line pull. 12000 Lbs (5443kgs) single line.
Motor. Series wound DC 12V with 6.0 hp /4.5kw output
Gear Train. 3 stage planetary
Gear ratio 265 : 1
Clutch Sliding Ring gear
Braking action automatic in the drum
Battery Recommended 650 CCA minimum for winching
Battery 2 gauge,72"(1.83m)
Fairlead 4-way Roller fairlead
Wire rope 3/8"X85'(9.5mmX26m)
Drum size 2.5"X8.8"(63.5mmX224mm)
Dimensions 21.6"X6.3"X8.6"(548mmX160mmX218mm)
N W. 42 kg |
|
|
|
|
